Name: FireBoundaryLine

Display Field: FIRE_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This Administration feature is the single most valuable feature maintained by the GIS Services staff. It combines the maintenance of many individual polygon features in one main overall feature.It is part of a ArcGIS Topology class maintained with our parcel and zoning features in the Editing Feature Data Set.We use the shared editing capabilities of this topology class to leverage our maintenance procedures as simply as possible. Weekly, the individual features maintained with our Administration feature are created with ArcGIS dissolve function. These include Jurisdiction boundaries, Public Safety Response areas, Voting Precincts, Schools Attendance Zones, Inspections, Library Service Zones, and more.Generally, maintenance of this feature is controlled thru shared editing performed with our parcel/zoning edits with the use of the Topology features in ArcGIS. Changes to features maintained in the Administration feature are caused by a number of issues. Parcel edits, new Public Safety Stations, changes in Voting Precincts, Police Reporting districts and other changes occur often. Most changes can be facilitated by selecting one or more “Administrative” polygons and changing the appropriate attribute value. Use of the “Cut Polygon” task may be necessary in those cases where part of a polygon must be changed from a district to another. The appropriate attribute can be changed in the affected area as necessary.

Service Item Id: df98ce33db6a4ed7bb984f04bfc8235f

Copyright Text: GIS Services Staff, Gary Coleman

Default Visibility: true

MaxRecordCount: 20000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.085923613008906E7
YMin: 3423496.929961726
XMax: 1.1283994219875634E7
YMax: 3817851.7698593885
Spatial Reference: 102747  (2284)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [140, 36, 136, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FIRE_NAME ( type: esriFieldTypeString, alias: FIRE_NAME, length: 50 )
• FIRE_NO ( type: esriFieldTypeString, alias: FIRE_NO, length: 50 )
• IRA ( type: esriFieldTypeString, alias: IRA, length: 50 )
• StationNo ( type: esriFieldTypeString, alias: StationNo, length: 255 )
• Station ( type: esriFieldTypeString, alias: Station, length: 255 )
• ID ( type: esriFieldTypeString, alias: ID, length: 255 )
• Shape_STArea__ ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape_STLength__ ( type: esriFieldTypeDouble, alias: Shape.STLength() )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
